Green Bank Solar Radio Burst Spectrometer
Background-Subtracted Mid Frequency Hourly Dynamic Spectra: 2009 02 09
Polarizations A and B are arranged vertically in separate images.
The frequency range is about 100 (bottom) to 300 MHz (top of each panel).
Dropouts occur if the 45-foot antenna loses tracking.
Vertical ticks every 10 minutes, horizontal ticks at 40 MHz intervals.
Vertical white lines (dotted lines on light curve) indicate local sunrise and sunset (to within 2 minutes).
Click on a panel to see a larger image (4 second resolution).
|10-11 UT||11-12 UT||12-13 UT||13-14 UT
|14-15 UT||15-16 UT||16-17 UT||17-18 UT
|18-19 UT||19-20 UT||20-21 UT||21-22 UT
